T-Section: Centroid and Section Modulus
A 200 × 30 mm flange on a 30 × 170 mm web: centroid 60.9 mm from the top, area 11,100 mm², I = 40.30 × 10⁶ mm⁴ and section moduli of 661 × 10³ mm³ (top) and 290 × 10³ mm³ (bottom).
