4–20 mA Loop Voltage Drop

A 2-wire transmitter loop with cable, barrier and load resistances (total drop 6.20 V), the minimum supply calculation (12.0 V + 6.20 V + 1.24 V margin = 19.44 V, so a 24 VDC supply), and reference tables for transmitter and receiver voltages and copper cable resistance by AWG.
